MLW RSD-17 (DL600B) |
 |
| Data Sheet Information Compiled by: Jean-Denis Bachand |
| New: 3 April 2005 |
Drawing by: Jacques Belanger |
| - |
| Engine Builder: Dominion Engineering Works |
Engine: 4-cycle Model 251B V16 |
| Bore & Stroke |
9" X 10.5" |
| RPM (Maximum / Minimum) |
1025 / 400 |
| Main Generator: GE - GT586 |
Horsepower: 2400 |
| Gear Ratio: 74:18 |
Speed: 65 mph |
| Tri-Mount 6-Wheel |
Configuration: C-C |
| Traction Motor Blowers: Mechanical Driven (2) |
Model: Stuart |
| Weight: 339,000 lbs |
Traction Motors: GE 752 (Six) |
| Tractive Effort (starting) 84,750 lbs @ 25% |
Tractive Effort (continuous): 79,500 lbs @ 12 mph |
| Multiple Unit Capability: Yes |
Dynamic Braking: Yes |
| Auxilary Generator: GE GY27 |
Alternator: |
| Air Brake: Westinghouse |
Model: 24RL |
| Compressor: Westinghouse |
Model: 3CDC |
| Boiler Type: -- |
Lbs/hr: -- |
| Quantity Built: 1
|
Dates: 5/1957 |
| - |
- |
| Exterior Dimensions
| RSD-17 |
| Total Length |
66'-07" |
| Pilot to Pilot |
61'-00" |
| Wheel Diameter |
40" |
| Truck Wheel Base |
12'-06" |
| Height to Top Engine Hood |
14'-09" |
| Height to Top Cab Hood |
14'-09" |
| Cab Width |
10'-01" |
| Top Walkway Width |
10'-01" |
| Walkway Width |
5'-01" |
| Engine Hood Width |
9'-11" |
| Center Bolster |
43'-06" |
| Center Front Truck to Front Pilot |
9'-04" |
| Center Rear Tucrk to Rear Pilot |
9'-04" |
| Distance between Truck Centers |
54'-08" |
| Minimum Turning Radious |
21 degrees |
| -
| - |
| Fuel Oil: 1350
| Lubricating Oil: 208 |
| Engine Cooling Water: 267
| Sand Capacity: 48 cu. ft. |
| Options: |
| - |
 |
| MLW RSD-12 Drawing by: Jean-Denis Bachand |
Reference Sources:
- MLW Design Data Books
- Canadian National Design Data Book
- Canadian Pacific Design Data Book
|
